Immersible vertical progressive cavity pump with bracket or flanges

Vertical Progressive Cavity Pump

Q=0.5-120m³/h (2.2 USGPM – 528 USGPM)

P=0~1.2Mpa (0~175 psi)

Vertical progressive cavity pump structural drawing

Home>PC Pumps>Vertical progressive cavity pump

What is a

vertical progressive cavity pump?

The vertical progressive cavity pump can be regarded as a horizontal progressive cavity pump working upright, and the inlet and outlet are exchanged. The biggest difference is that the stator of the suction inlet has a horn shape, and the support method is bracket support or ring installation, and it can also be equipped with a lift truck.

Features
Parameter Table
Applications
Document
Request Quote

vertical-progressive-cavity-pump-Mingjie

Stainless steel vertical progressive cavity pump

Multiple installation methods (bracket installation, hoisting ring installation, fixed on lifting carts, etc.)
With horn-shaped stator, strong self-priming ability
Long conveying distance
Can operate under high delivery pressure and high capacity
Able to pump multiple substances
Flow can be adjusted proportionally
Long life cycle and low cost
Easy to disassemble and repair, not time-consuming
Perfect measurement accuracy

Pump Type	Pressure Range (bar)	Capacity Range (m³/h)	Speed Range (rpm)	Inlet Size (G/DN)	Outlet Size (G/DN)	Motor Power (KW)
MJN025-2S	0~12	0~0.25	0~350	G1¼	G1¼	0.37
MJN05-1L	0~6	0~0.5	0~350	G1¼	G1¼	0.37
MJN05-2S	0~12	0~0.5	0~350	G1¼	G1¼	0.75
MJN1-1L	0~6	0~1	0~350	G1¼	G1¼	0.75
MJN1-2S	0~12	0~1	0~350	50	50	1.5
MJN1-4S	0~24	0~0.5	0~250	50	50	3
MJN3-1L	0~6	0~3	0~350	50	50	2.2
MJN3-2S	0~12	0~2.5	0~350	65	65	3
MJN3-4S	0~24	0~1.5	0~250	65	65	5.5
MJN5-1L	0~6	0~5	0~320	65	65	3
MJN5-2S	0~12	0~5	0~320	80	80	4
MJN5-3S	0~18	0~3	0~250	80	80	5.5
MJN5-4S	0~24	0~2	0~200	80	80	7.5
MJN10-1L	0~6	0~10	0~300	80	80	4
MJN10-2S	0~12	0~7	0~300	80	80	5.5
MJN10-3S	0~18	0~6	0~250	80	80	7.5
MJN10-4S	0~24	0~4	0~200	80	80	11
MJN15-1L	0~6	0~15	0~300	80	80	5.5
MJN15-2S	0~12	0~12	0~300	100	100	7.5
MJN15-3S	0~18	0~10	0~250	100	100	11
MJN15-4S	0~24	0~7	0~200	100	100	15
MJN25-1L	0~6	0~25	0~280	100	100	7.5
MJN25-2S	0~12	0~22	0~300	125	125	11
MJN25-3S	0~18	0~15	0~250	125	125	15
MJN25-4S	0~24	0~12	0~200	125	125	18.5
MJN50-1L	0~6	0~50	0~280	125	125	11
MJN50-2S	0~12	0~35	0~250	150	150	22
MJN50-3S	0~18	0~30	0~230	150	150	30
MJN50-4S	0~24	0~26	0~200	150	150	37
MJN80-1L	0~6	0~80	0~280	150	150	22
MJN80-2S	0~12	0~60	0~280	150	150	37
MJN80-3S	0~18	0~42	0~200	150	150	45
MJN80-4S	0~24	0~25	0~150	150	150	55
MJN120-1L	0~6	0~120	0~250	150	150	37
MJN120-2S	0~12	0~100	0~270	200	200	45
MJN120-3S	0~18	0~60	0~180	200	200	55
MJN120-4S	0~24	0~50	0~150	200	200	55
MJN180-1L	0~6	0~180	0~220	200	200	45
MJN180-2S	0~12	0~170	0~220	200	200	55
MJN300-1L	0~6	0~300	0~220	200	200	55

Mingjie Progressive cavity Pump Parameter Table

Such as sewage tanks, fruit and vegetable juice buckets, ponds or pits.

Containers used to empty environmentally hazardous substances. In this case, it is generally not allowed to empty through the bottom flange of the container;

Suspension bracket is used for crane suspension or dome-shaped cover flange immersion pump for low pulsation emptying or delivery of open or closed barrels, tanks, clarifiers, pits and similar containers.
